Design Guide for the Polycom SoundStructure C16, C12, C8, and SR12
A - 58
Description
Set the gain of the specified band in the graphic equalizer. The index must be
between 1 and 10 for 1 octave equalization, between 1 and 15 for 2/3 octave
equalization, and between 1 and 31 for 1/3 octave equalization.
geq_type Graphic Equalizer Type
Description
This parameter sets the type of the graphic equalizer.
high_shelf_en Enable High Shelving Filter
Virt Chans Mono, Stereo
Indices 1-31: Band number
System Limits Minimum: -20.0, Maximum: 20.0, Resolution: 0.01
Default 0.0
User Limits
Supported
No
Argument Argument value
Argument Argument value
Channel Type Virtual Channel
Value Type List
Read/Write Mode Read/Write
Phys Chans Conferencing Line Output, Sound Reinforcement Line
Output
Virt Chans Mono, Stereo
Values 1 : octave (10 band)
2/3 : 2/3 octave (15 band)
1/3 : 1/3 octave (31 band) (default)
Argument Argument value
Channel Type Virtual Channel
Value Type Boolean
Read/Write Mode Read/Write
