Chapter 1- Hardware Description

1-12

SLOT (1-4)

LEDs

LNK (1-4) Green Lit with active network

connection, flickers with Packet

activity.

1Gb (1-4) Amber Lit when 1Gb connection online,

flickers with Packet activity.

ShMC LEDs ERR Red ON - Major error on RTM board.

ACT Red ON - Packet flow to and from

the MCU chassis.

RDY Green ON - RTM IP board has

successfully completed startup.

HS Blue OFF - Normal.

Flashes - During shut down

process. This is activated by

light push on the RTM IP

board’s ejector mechanism.

ON - RTM IP board may be

removed.

Standby LED Red ON - CPU & System are in a

standby (OFF) mode.

Table 1-5 RMX 2000 Rear Panel LEDs (Continued)

Function Name

LED

Name

LED Color Description
