SpectraLink Corporation NetLink e340/h340/i640 Wireless Telephones and Accessories User Guide

Part Number: 72-1004-01-J.doc

Page 12

Using the Softkeys

The softkeys on your NetLink Wireless Telephone enable you to

quickly activate system features. There are four softkeys and up to

16 features programmed for softkey access. See the Appendices for

variations when protocols other than SRP are used. The display area

directly above each softkey is programmed with a feature

abbreviation to guide your access to the feature. The softkeys are

referred to from left to right as A,B,C,D. In our diagram, the

corresponding display area is labeled Aaaa, Bbbb, Cccc, Dddd.

The softkeys operate with a toggle function. Press the left or right

side of the key to activate the corresponding softkey feature.

View Softkey functions

The first four primary softkey features are displayed in the softkey

function display area by default. To view all of the features that can

be activated through the softkeys, go off hook (briefly press the

Start Call key) and then press the FCN key. The second set of feature

abbreviations will display in the softkey display area. Each time the

FCN key is pressed, a different set of features is displayed, until all 16

possible features have been displayed. The softkey features display

in the same sequence as they appear on the Shortcut Menu.

Activate any feature while its abbreviation is displayed by pressing

the corresponding softkey.

Using the Shortcut keys

While scrolling through the softkey functions, a shortcut key may be

pressed to activate its corresponding feature, whether or not that

feature is currently displayed in the softkey function display area.

Because system features vary, your system administrator will explain

them in reference to your telephone system.

Example:

Using the previous example for the Transfer function: If the

Transfer function is assigned to softkey A in the second level row,

then

Xfr will display in the Aaaa softkey display area when the FCN

key is pressed. Therefore, while in a call press

FCN + (softkey A) to

transfer the call.

Alternately, you may use the shortcut key by pressing

FCN + 2. You

may also press

MENU + 2 as described in the Shortcut Menu section

above.

Note:

PBX systems function differently. If your handset does not conform

to these instructions, contact your system administrator for function

clarification.

* See the Appendices for variations when protocols other than SRP are used.
